FA-120R 6 Zone 120W Mixer Amplifier

6-Zone Commercial Mixer Power Amplifier – Rack Mount PA System

Engineered for versatile commercial audio applications, this 6-zone public address (PA) mixer amplifier is a powerful and reliable solution for delivering clear announcements and background music across multiple zones in buildings such as malls, schools, offices, and warehouses.

🔹 Key Features:

• Powerful Output Options
  Available in 60W, 120W, 240W, 350W, and 500W models to suit varying installation needs.

• Zone Management
  Supports 6 separate speaker zones, each with independent volume control. Outputs available in 100V or 70V.

• Flexible Audio Sources
  Integrated MP3 player via USB/SD, FM tuner, and Bluetooth connectivity for seamless media playback.

• Multiple Microphone & Line Inputs

  • Mic1 (6.3mm) with VOX priority

  • Mic/Line 2-4 (XLR)

  • Line 1-2 (RCA)

  • EMC input (RCA) with highest emergency priority

• Remote Paging
  Supports up to 6 remote paging microphones (FA-60RM) with a distance of up to 300 meters.

• User-Friendly Front Panel Controls
  Independent volume controls for all mic and line inputs, bass & treble adjustment, zone volume control, and visual output level meters.

• Reliable & Protected Operation
  Features overload, short circuit, and high temperature protection, with visual indicators for power, protection, clipping, and zone status.

• Dual Power Supply
  Operates on both AC 230V and DC 24V power sources, ensuring uninterrupted performance.

• Rack Mount Design
  Compact 2U height, suitable for standard 19” rack installations.
